Mercury Analyzer HG-MP (Gas Phase)

Article number: HG-MP

Product details

Highly sensitive, continuous UV mercury analyzer for measurement of mercury in gas and water.
+ No calibration, no zero drift
+ Patented “ONE BEAM” technology
+ Fully digitally operated
+ No adjustments
+ Highest sensitivity
+ Ranges switchable
+ 19” mechanics
+ Temperature / pressure compensation
+ Auto zero drive
+ Selective filter
+ Mobile use
+ Analog / digital output
+ Software for data log
+ Software for gas bag monitoring
+ Integrated flow meter with needle valve
+ Patent USA 5,334,536. DE 41 19 346

Applications

Hg emission / immission monitoring, Hg monitoring
Water / soil
Natural gas
Working areas (TLV)
Chemical separation processes
Physical adsorption processes
Recycling processes
Chemical electrolysis
Medical / dental appliances using gas bag reservoirs

Industries

Technical data

Principle: single beam photometer (Patent: DE 41 19 346, US 5,334,536)
Units: ppmv
Measuring range SI: Gas: 0-1/10/100/1000 µg/Nm3, Water: 0-10 µg Hg/l, 0-30 mg Hg/l
Sample port: ¼” – 6/4 mm PFA tube
Gas flow rate: 100 – 200 Nl/h
Dimensions: 19” / 3HU / 450 mm
Analog signal output: 0/4 – 20 mA
Digital signal output: Interface RS232
Alarm signal: adjustable 4 x potential-free change-over contact
Power supply: 230/110 VAC – 50/60 Hz

Please contact for further info.
